3-9
Cisco Unified IP Phone Services Application Development Notes
OL-20949-01
Chapter 3 CiscoIPPhone XML Objects
XML Object Definitions
Example
The following XML code defines a
CiscoIPPhoneImage
object that displays the sequence of pixels shown
as a graphic positioned at the center of the phone display:
2D
The graphic display comprises a contiguous stream of hexadecimal digits, with no spaces or other
separators. If the number of pixels to be displayed does not represent an even multiple of four, pad the
end of the pixel data with blank (zero value) pixels, so the data is packed correctly. The phone ignores
the padded data.
Tip
Before displaying a graphic image on a Cisco Unified IP Phone, the software clears the pane dedicated
to services. If a service has text or other information that must be preserved (including the title area), the
information must get redrawn as part of the graphic. If the title is to be hidden, the graphic must be large
enough to cover it.
CiscoIPPhoneImageFile
The latest generation of Cisco Unified IP Phones have higher-resolution displays with more color depth.
The Cisco Unified IP Phone 7970G, for example, has a display area of 298x168 pixels available to the
Services pane and renders images in 12-bit color.
To support these more advanced displays, a new XML object allows the use of color PNG images in
addition to the grayscale
CiscoIPPhoneImage
objects. The
CiscoIPPhoneImageFile
object behaves like
the
CiscoIPPhoneImage
object, except for the image data. Instead of using the
tag to embed the
image data, the
tag points to the PNG image file.
The web server must deliver the PNG image to the phone with an appropriate MIME Content-Type
header, such as image/png, so the phone recognizes the content as a compressed, binary PNG image. The
PNG image can be either palettized or RGB, and the maximum image size and color depth are model
dependent (see
Table 3-2
Cisco Unified IP Phones Display Image Sizes and Color Depths
Model
Resolution
1
(width x height)
Color/Grayscale
/Monochrome
Color Depth (bits)
Cisco Unified IP Phones 7905G, 7906G,
7911G, 7912G
2
, 7931G
N/A
Grayscale
1
Cisco Unified IP Phone 7920
128 x 59
Grayscale
1
Cisco Unified IP Phone 7921G, 7925G
176 x 140
Color
16
Cisco Unified IP Phones 7940G/60G
133 x 65
Grayscale
2
Cisco Unified IP Phones 7941G, 7941G-GE,
7942G, 7961G, 7961G-GE, 7962G
298 x 144
Grayscale
4
