3-6
Cisco Unified IP Phone Services Application Development Notes
OL-20949-01
Chapter 3 CiscoIPPhone XML Objects
XML Object Definitions
During text entry, Cisco Unified IP Phones display softkeys to assist users with text entry. Users can
navigate between fields with the vertical scroll button that is used to navigate menus, and so on.
CiscoIPPhoneDirectory
The phone originally incorporated the CiscoIPPhoneDirectory XML object to support the Directory
operation of Cisco Unified IP Phones, but it is available for your development purposes also. Figure 3-2
shows how an XML CiscoIPPhoneDirectory object displays on the phone.
Figure 3-2 CiscoIPPhoneDirectory Object Display Sample
Definition
Directory title goes here
Prompt text goes here
The name of the directory entry
The telephone number for the entry
InputFlag Description
A Plain ASCII text—use the DTMF keypad to enter text that consists
of uppercase and lowercase letters, numbers, and special characters.
T Telephone number—enter only DTMF digits for this field. The
acceptable input includes numbers, #, and *.
N Numeric—enter numbers as the only acceptable input.
E Equation—enter numbers and special math symbols.
U Uppercase—enter uppercase letters as the only acceptable input.
L Lowercase—enter lowercase letters as the only acceptable input.
P Password field—enter individual characters using the standard
keypad-repeat entry mode. The system automatically converts
accepted characters into an asterisk, keeping the entered value
private.
Note P specifies the only InputFlag that works as a modifier. For
example, specify a value of “AP” in the InputFlag field to
use plain ASCII as the input type and to mask the input as a
password by using an asterisk (*).
