CARTON CONTENT
]
1.
Housing Assembly
12.
Hanger Bracket Assembly R.H
2.
Lift Handle and Cable
13.
Hanger Bracket Assembly L.H.
3.
Chute Crank
Rod
Assembly
14.
Rear Frame Bracket L.H.
4.
Support Tube, Crank Rod
15.
Rear Frame Bracket R.H.
5.
V-Belt, Drive 52" (#41353)
16.
Front Frame Bracket L.H.
6.
V-Belt, Drive 55" (#46989)
17.
Front Frame Bracket R.H.
7.
Chute and Control Cable Assembly
18.
Support Link (2)
8.
Clutch Idler Assembly
19.
Support Tube (2)
9.
Anti-rotation Bracket
20.
Side Plate L.H.
10.
11.
V-Belt, Auger (Attached to Housing Assembly)
Frame Brace
21.
Side Plate R.H.
ONLY ITEMS NEEDED FOR MODEL 247. TRACTORS ARE SHOWN
