REPAIR PARTS FOR MODEL 486.248371 42" SNOW THROWER
(For Tractors With Model Numbers Beginning With 247)
REF PART NO QTY DESCRIPTION REF PART NO QTY DESCRIPTION
1 05931 1 Housing, Bearing 40 43182 2 Hex Bolt, 5/16x3/4"
2 65701 1 Housing Assembiy 41 43086 2 Lock Washer, 5/16"
3 71464 1 Gear Assembiy 42 47134 2 Hairpin Cotter, .08 x 1.58"
4 63579 1 Chute Crank Rod Assembly 43 41576 2 Hex Bolt, 3/8-16x1-3/4"
5 63768 1 Impeller Assembly 44 44377 1 Hex Bolt, 3/8-24 x 1"
6 24773 1 Scraper Plate 45 784-5594 1 Bracket, Cable
7 25982 1 Shaft, Auger Gearbox 46 746-0929 1 Cable, Chute Control With Clip
8 703-2735A 1 Bracket, Chute Crank 47 711-0242 2 Spacer
9 24816 1 Cover, Belt 48 746-0928 1 Cable, Chute Control
10 705-5226 1 Chute Reinforcement 49 HA21362 4 Hex Nut, 3/8-16 Nylock
11 705-5269 1 Spiral Assembly, L.H. (not shown) 50 43038 2 Pin, Pivot Lock
12 705-5270 1 Spiral Assembly, R.H. 51 43343 2 Pin, Hair Cotter #4 (1/8")
13 43840 2 Hex Bolt, 5/16-18x1-1/4" Lg. 52 43064 2 Lock Nut, 5/16"
14 44950 4 Carriage Bolt, 1/4-20 x 3/4" 53 24394 1 Bracket, Chute Anti-rotation
15 44917 1 Palnut, 3/8" 54 47572 2 Hex Lock Nut, 3/8-16 Flanged
16 44326 4 Carriage Bolt, 5/16-18 x 1" Lg. 55 1643-60 1 Plastic Cap
17 43080 10 Carriage Bolt, 5/16-18 x 3/4" Lg. 56 67052 1 Hanger Bracket Assembly, R.H.
18 46703 6 Bolt, Self-Tap 5/16" x 3/4" 57 67053 1 Hanger Bracket Assembly, L.H.
19 710-0890A 2 Bolt, Shear 5/16-18x1-1/2" 58 43063 2 Hex Bolt, 5/16x1"
20 43088 11 Washer, 1/4" 59 48106 2 Bolt, Shoulder
21 43070 2 Washer, 3/8" 60 24466 2 Bracket, Down Stop
22 47189 4 Hex Nut, 1/4-20 Nylock 61 736-0247 1 Washer,
23 47810 29 Hex Nut, 5/16-18 Nylock 62 47598 6 Hex Lock Nut, 1/4" Flanged
24 715-0114 2 Spiral Pin, 1/4" X 1-1/2" Lg. 63 731-0921 1 Chute, Upper
25 750-0437 1 Bushing 64 731-1313C 1 Guide, Cable
26 731-1379A 1 Chute Adapter 65 47044 2 Pulley, V Type 4"
27 43086 4 Lock Washer, 5/16" 66 47026 1 Pulley, VType
28 43009 6 Washer, .785" x 1.57" x .057" 67 43085 1 Hex Bolt, 5/16-18x1-1/2"
29 711-0469 4 Spacer, .75 ID x 1.25 OD x .5 L 68 710-0896 1 Screw, 1/4-14x5/8"
30 43081 26 Washer, 5/16" Std.Wrt. 69 731-0851A 3 Chute Keeper
31 47615 2 Bearing, Flange 70 43661 6 Hex Bolt, 1/4-20 X 1"
32 741-0309 1 Bearing, Ball 71 731-1300C 1 Chute, Lower
33 741-0475 2 Bushing, Plastic 3/8" 72 25937 1 Center Brace, Gearbox
34 741-0493A 4 Bearing, Split, 3/4" 73 HA20185 1 #61 Woodruff Key
35 24279 2 Skid Shoe 74 43182 3 Hex Bolt, 5/16-18x3/4"
36 48015 4 Washer, Nylon 75 44940 1 Carriage Bolt, 1/4-20 x 3/4"
37 784-5618 2 Housing, Bearing 76 67266 1 Rear Frame Bracket, R.H.
38 24393 1 Bracket, Chute Crank 77 67267 1 Rear Frame Bracket, L.H.
39 27280 1 Bracket, Idler 42317 1 Owner's Manual
23
