REPAIR PARTS FOR MODEL 486.248371 42" SNOW THROWER
(For Tractors With Model Numbers Beginning With 247)
REF
PART NO QTY
DESCRIPTION
REF
PART NO QTY
DESCRIPTION
1
64637
1
Lift Shaft Assembly
38
46446
1
Grip, Handle
2
710-0865
2
Hex Bolt, 1/2-13x1"
39
47027
1
Tube, Crank Rod Support
3
710-0367
2
Hex Bolt, 5/8-11
X
1-1/2"
40
741-0475
2
Bushing, 3/8" Plastic
4
711 -0332
2
Pin, Bracket Lift
41
703-2735A
1
Bracket, Chute Crank
5
712-0261
2
Nut, Hex Lock 5/8-11 Thread
42
720-0201A
1
Knob, Crank
6
43262
6
Nut, Hex Lock 1/2-13
43
44917
1
Palnut, 3/8"
8
142
5
Pin, Cotter 1/8"
X
3/4"
45
63579
1
Assembly, Chute Crank Rod
9
43093
1
Pin, Cotter 1/8"
X
1-1/2"
46
784-5604A
1
Handle, Chute Tilt
10
R19171616
4
Washer, 17/32" x1"
47
720-04039
1
Knob
11
41346
2
Support Link
48
603-0302
1
Assembly, Chute Tilt Bracket
12
741-0192
2
Bearing, Flange With Flats
49
731-1313C
1
Guide, Cable
13
783-0380
2
Link, 15.80" Long
50
746-0928
1
Cable, Chute Control
14
783-0381
2
Link, 11.75" Long
51
746-0929
1
Cable, Chute Control with Clip
15
24476
2
Link, 4.88" Long
52
43064
5
Nut, Hex Lock 5/16-18
16
24311
1
Rod, Spacer
53
43081
2
Washer, 5/16"
17
47599
2
Hex Bolt, 5/16-18x1" (Locking)
54
24285
1
Plate, Mounting (L.H.)
18
43086
4
Lock Washer, 5/16"
55
24284
1
Plate, Mounting (R.H.)
19
24820
1
Bracket, Lift
56
43601
1
Washer, 1.59" x 1.032" x .060"
20
63773
1
Assembly, Handle Lift Bracket
57
712-3083
4
Nut, Nylock Hex 1/2-13
21
48049
1
Rod, Index Lift
58
R19172410
8
Washer, 1/2"
22
47369
1
Pin, Spring 3/16"
X
1-3/4"
59
726-0178
3
Tie, Nylon
23
732-0306
1
Spring, Compression
60
43020
2
Hex Bolt, 1/2"
X
1-1/2"
24
R19131316
2
Washer, 13/32" x 13/16"
61
27231
2
Spacer, 1/2"
25
47788
2
Reflector, Rear
62
47572
6
Nut, Flanged Lock 3/8-16
26
43080
1
Carriage Bolt, 5/16-18 x 3/4"
63
47810
8
Nut, Nylock Hex 5/16-18
27
43182
2
Hex Bolt, 5/16-18x3/4"
64
43084
2
Hex Bolt, 5/16-18x1-3/4"
29
47368
1
Pin, Spring 5/16"
X
1-3/4"
65
25722
1
Frame Brace
30
46954
1
Pin, Attachment
66
48106
2
Bolt, Shoulder
31
43343
1
Pin, Haircotter #4 (1/8")
67
44695
2
Washer, Bowed
32
67268
1
Plate, Side (R.H.)
68
43682
2
Carriage Bolt, 5/16-18 x 1-1/4"
33
67269
1
Plate, Side (L.H.)
69
44215
2
Carriage Bolt, 5/16-18 x 1 -3/4"
34
49916
1
Tube, Lift Handle
70
41352
2
Support Tube
35
49912
1
Trigger and Lift Cable Assembly
71
43351
2
Hex Bolt, 1/2"
X
1-1/4"
36
43019
4
Nut, Hex Jam 1/2-13
72
47134
2
Small Hairpin Cotter
37
710-1233
1
Screw, Oval #10-24 x 1"
73
714-04061
2
Quick Release Pin
