General Configuration Screen
6H128-08 and 6H129-08 User’s Guide 5-41
Figure 5-18 General Configuration Screen
The following briefly explains each General Configuration screen field:
MAC Address (Read-Only)
Displays the base physical address of the module.
IP Address (Modifiable)
This display allows the IP address to be set for the 6H12X-08. To set the
IP address, refer to
Section 5.15.1 .
Subnet Mask (Modifiable)
Displays the subnet mask for the module. A subnet mask “masks out” the
network bits of the IP address by setting the bits in the mask to 1 when the
network treats the corresponding bits in the IP address as part of the
network or subnetwork address, or to 0 if the corresponding bit identifies
the host. When an IP address is entered in the IP address field, the subnet
mask field automatically enters the default subnet mask for the IP address.
For details about how to change the subnet mask from its default value,
refer to
Section 5.15.2 .
Firmware Revision: XX.XX.XX
General Configuration
2159-16
BOOTPROM Revision: XX.XX.XX
MAC Address:
IP Address:
Subnet Mask:
Default Gateway:
TFTP Gateway IP Addr:
Module Date:
Module Time:
Screen Refresh Time:
Screen Lockout Time:
Com 1: [ENABLED] Application: [LM]
Clear NVRAM: [NO]
Module Uptime XX D XX H XX M
Module Type: 6H128-08
Slot Number: X
IP Fragmentation [ENABLED]
EXIT
Operational Mode: [802.1D SWITCHING] Management Mode: [DISTRIBUTED]
00-00-ID-00-00-00
0.0.0.0
255.255.0.0
NONE DEFINED
0.0.0.0
6H128-08 LOCAL MANAGEMENT
Event Message Line
RETURN SAVE
10/11/97
14:23:00
30 sec.
15 min.
