6H128-08 and 6H129-08 User’s Guide 4-1
CHAPTER 4
TROUBLESHOOTING
This chapter provides information concerning the following:
• Using the LANVIEW diagnostic and status monitoring system
• Troubleshooting network and module operational problems
• Using the RESET button
For more troubleshooting information about other Cabletron products,
please refer to the Cabletron Systems Guide to Network Troubleshooting.
See
Section 1.8 for information on obtaining the guide.
4.1 USING LANVIEW
The 6H12X-08 uses Cabletron Systems built-in visual diagnostic and
status monitoring system called LANVIEW. The LANVIEW LEDs
(Figure 4-1) allow quick observation of the network status to aid in the
diagnosing of network problems. Refer to
Table 4-1 for a description of
the LEDs.
For a functional description of the LANVIEW LED on the optional Fast
Ethernet Interface Module (FE-100TX), refer to
Section 4.2 .
NOTE
The terms flashing, blinking, and solid used in the following
table indicate the following:
Flashing indicates an LED flashing randomly.
Blinking indicates an LED is flashing at a steady rate, for
example, approximately 50% on, 50% off.
Solid indicates a steady LED light (no pulsing).
