Appendix A: Specifications
A-2
6H128-08 and 6H129-08 User’s Guide
A.4
INPUT/OUTPUT PORTS
6H128-08 and 6H129-08 Specifications
A.5
COM PORT PINOUT ASSIGNMENTS
The COM port is a serial communications port that supports Local
Management or connection to a UPS.
The COM port has the following pin assignments:
Ports 1 through 6
Fast Ethernet (100BASE-FX compliant)
with SC type connectors. 6H128-08 uses
multimode fiber, and the 6H129-08 uses
single mode fiber.
Slots for optional Fast
Ethernet Interface Modules
(ports 7 and 8)
Slots accept optional Fast Ethernet
Interface Modules: the FE100-TX,
FE100-FX and the FE-100F3, also check
the Release Notes for other Modules that
may be available.
Table A-1
COM Port Pin Assignments
Pin
Signal Name
Input/Output
1
Transmit Data (XMT)
Output
2
Data Carrier Detect (DCD)
Output
3
Data Set Ready (DSR)
Input
4
Receive Data (RCV)
Input
5
Signal Ground (GND)
NA
6
Data Terminal Ready (DTR)
Output
7
Request to Send (RTS)
Input
8
Clear to Send (CTS)
NA
