Module Statistics Menu Screen
6H128-08 and 6H129-08 User’s Guide 5-85
To access the Module Statistics Menu from the Module Menu screen, use
the arrow keys to highlight the MODULE STATISTICS menu item and
press ENTER. The Module Statistics Menu
screen displays.
Figure 5-31 Module Statistics Menu Screen
The Module Statistics Menu screen displays the following menu items:
SWITCH STATISTICS
The Switch Statistics screen lists the number of frames received,
transmitted, filtered, and forwarded by each port. For details refer to
Section 5.26 .
INTERFACE STATISTICS
The Interface Statistics screen provides the MIB-II statistics for each
switched interface, on an interface-by-interface basis. For details, refer to
Section 5.27 .
RMON STATISTICS
The RMON Statistics screen displays all the statistics gathered by the
embedded RMON agent built into the 6H12X-08. For details, refer to
Section 5.28 .
Firmware Revision: XX.XX.XX
Module Statistics Menu
SWITCH STATISTICS
INTERFACE STATISTICS
RMON STATISTICS
22511-67
Module Type: 6H128-08
BOOTPROM Revision: XX.XX.XX
6H128-08 LOCAL MANAGEMENT
EXIT RETURN
Slot Number: X
