Broadcast Suppression Screen
6H128-08 and 6H129-08 User’s Guide
5-83
Figure 5-30
Broadcast Suppression Screen
The following explains each field of the Broadcast Suppression screen:
Port # (Read-only)
Identifies the number of the port.
Total RX (Read-Only)
Displays the total number of broadcast frames received.
Peak Rate (Read-Only)
Displays the number of broadcast frames received per second.
Time Since Peak (Read-Only)
Displays the time since peak broadcast frames received.
Threshold (Modifiable)
Allows the user to set, in increments of ten, the desired limit of receive
broadcast frames that will be forwarded per port per second.
Reset Peak (Modifiable)
Allows the user to reset the peak rate. The Time Since Peak field will also
reset. The Reset Peak field toggles between YES and NO.
