Parts List for Craftsman Lawn Utility Vehicle Model 247.270250
Key No.
Part No.
Description
Key No.
Part No.
Description
1.
757-04000
Seat
38.
710-1752
Special Screw
2.
683-0575
Support Bracket Assembly LH
39.
711-1165
Clevis Pin
3.
683-0576
Support Bracket Assembly RH
40.
712-0185
Speed Nut 1/4-20 *
4.
710-0604A
TT Screw 5/16-18
X
0.625”
42.
712-0640
Hex Nut
5.
710-1250
Carriage Bolt 5/16 x 1.5”
43.
712-0692
Hex Lock Nut
6.
710-1681
HexBoltM8-1.25;20
44.
712-0714
Flange Lock Nut
7.
710-1690
Special Screw M6-1:16
45.
714-0470
Cotter Pin
8.
710-1703
Hex Bolt M8-1.25:45
46.
723-0491
Tray
9.
712-0431
Flange Lock Nut 3/8-16
47.
723-0604
Foot Pad
10.
712-0689
Hex Nut M6-1
48.
728-0285
Rivet
11.
712-0692
Hex Lock Nut M8-1.25
49.
731-04013
Battery Cover*
12.
712-3004A
Flange Lock Nut 5/16-18
50.
731-2360
Bag Tray
13.
726-3046
Ratchet Clip
51.
736-0187
Flat Washer .64 x 1.24 x ,06
14.
732-0735
Compression Spring
52.
736-0700
Flat Washer 8.4x16
15.
732-0750A
Actuator Spring
53.
736-0765
Lock Washer M4
16.
732-0996
Compression Spring
55.
750-1293
Spacer
17.
732-0997
Compression Spring
56.
783-04004
Bracket: Battery Support
18.
736-0105
Bell Washer .375 x .870 x .063
57.
783-1081A
Frame
19.
736-0289
Shoulder Bushing
58.
783-1097
Rear Bracket: Pivot Support
20.
736-0648
Lock Washer
59.
783-1101
Support Bracket: Transmission
21.
736-0743
Flat Washer 8.4 x 35
60.
783-1148
Chute Bracket
22.
738-1014
Shoulder Screw
61.
783-1260
Stop Bracket: Pivot
23.
749-1264
Support T ube: Seat
62.
783-1292
Cable Bracket
24.
783-04005
Seat Bracket
63.
710-0654A
TT Sems Screw 3/8-16 x 1.0
25.
783-0733
Spacer
64.
783-1294
Beit Keeper Bracket
26.
783-0931
Bag Switch Bracket
65.
710-1683
HexBoltM8-1.25:30
27.
783-1118A
Seat Support Bracket
66.
711-1065
Pin: Belt Guard
28.
17962
Switch Plate
67.
712-0692
LockNutM8-1.25
29.
683-0142
Pivot Bar Assembly
68.
712-3010
Hex Nut 5/16-18
30.
683-0581
Support Bracket Assembly RH
69.
722-0153
Engine Mount: Gromm.
31.
683-0591
Bracket Assembly: Steering Column 70.
736-0119
Lock Washer 5/16
32.
683-0593
Pivot Support Bracket: Front
71.
736-0701
Flat Washer 8.4 x 24
33.
710-0224
Ab Screw #10-1
6 X
0.5"
72.
747-1292
Belt Keeper Rod
34.
710-0599
TT Screw 1/4-20x0.5”
73.
750-0539
Spacer
35.
710-0946
Machine Screw *
74.
783-1120
Mounting Plate
36.
710-1681
Hex Screw M8-1.25:20
75.
725-1698
Battery*
37.
710-1708
Special Screw
76.
710-0870
Self-Tapping Screw
' If equipped
