Parts List for Craftsman Lawn Utility Vehicle Model 247.270250
Key No. Part No. Description Key No. Part No. Description
1. 731-1687 Steering Wheel 53. 746-1129 Brake Cable
2. 731-1459A Steering Wheel Cap 54. 747-1228A Shift Rod
3. 647-0055 Shift Pivot Assembly 55. 747-1240 Variable Control Rod
4. 683-0432 Drive Pedal Assembly 56. 747-1249 Control Rod
5. 683-0433 Brake Pedal Assembly 57. 747-1254 Shift Rod
6. 683-0592 Idler Brake Assembly 58. 747-1255 PTO Lever
7. 710-0191 Hex Bolt 3/8-24x1.25” 59. 747-04024 Brake Lock -Out Rod
8. 710-0599 TT Screw 1/4-20x0.5” 60. 747-1262 Belt Keeper Rod
9. 710-0604A TT Screw 5/16-18 X 0.625” 61. 783-1142 Shift Switch Bracket
10. 710-0859 Hex Bolt 3/8-16x2,5” 62. 783-1253 Shift Index Bracket
11. 710-1017 AB Screw 1/4-14x0.625" 63. 783-1287 Brake Mounting Bracket
12. 710-1681 Hex Bolt 64. 783-1293 Cont. Bracket: PTO
13. 710-3013 Hex Bolt 1/4-20x0.50” 65. 783-1307 Link Bracket
14. 711-0242 Spacer 66. 650-0007 Steering Tube Assembly
15. 711-0396 Spacer 67. 683-0033A Steering Support Bracket Assembly
16. 711-1155 Ferrule 68. 683-0178A Front Axle RH
17. 711-1531 Shaft 69. 683-0179A Front A)de LH
18. 712-0296 Jam Nut 3/8-24 70. 710-0459A Hex Bolt 3/8-24 X 1.5”
19. 712-0380 Flange Lock Nut 1/4-28 71. 710-0643 Hex Bolt 5/16-18 X 1.0"
20. 712-0431 Flange Lock Nut 3/8-16 72. 710-0689 Hex Bolt 1/2-13x0.75”
21. 712-0692 Nylon Lock Nut 73. 710-0837 AB Screw #10-16 x 0.625”
22. 712-0714 Flange Lock Nut 5/16-18 74. 710-0958 Hex Bolt 1/4-20x1.25"
23. 712-3007 Jam Nut 5/16-18 76. 712-0116 Jam Lock Nut 3/8-24
24. 712-3017 Hex Nut 3/8-16 77. 712-0206 Hex Nut 1/2-13
25. 714-0104 Cotter Pin 78. 712-0241 Hex Nut 3/8-24
26. 714-0145 Click Pin 79. 712-0324 Hex Lock Nut 1/4-20
27. 714-0149B Hairpin Clip 80. 712-0411 Hex Lock Nut 5/16-24
28. 714-0470 Cotter Pin 81. 712-0692 Hex Lock Nut
29. 720-0232 Shift Knob 84. 723-0156 Ball Joint 3/8-24
30. 720-0269 Clutch Grip 85. 731-0559B Steering Bellow
31. 726-0272 Clamp 86. 736-0105 Bell Washer
32. 732-0445 Extension Spring 89. 736-0196 Flat Washer.628 x 1.56 x .036
33. 732-0594A Extension Spring 90. 736-0242 Bell Washer .340 x .872 x .060
34. 732-1167 Compression Spring 91. 736-0272 Flat Washer .510 x 1.0 x .060
35. 732-3091 Compression Spring 92. 736-0320 Flat Washer 3/8 x 1.37
36. 735-0283 Drive Pad 93. 736-3078 Flat Washer .344 x 1.0 x .063
37. 735-3049 Brake Pad 94. 738-0541 Spacer
38. 736-0148 Lock Washer 95. 738-3089A Steering Adapter
39. 736-0160 Flat Washer.53 x .93 x .050 96. 741-0225 Hex Flange Bearing
40. 736-0169 Lock Washer 3/8 97. 741-0356 Bearing: Steering Column
41. 736-0187 Flat Washer 98. 747-0955 Tie Rod
42. 736-0267 Flat Washer 99. 748-0290 Pinion Gear
43. 736-0270 Bell Washer 100. 750-0532 Spacer
44. 736-0314 Thrust Washer 101. 783-1302 Steering Gear
45. 736-0701 Flat Washer 102. 783-1129 Cover: Steering Column
46. 736-0734 Flat Washer 103. 634-0169A Complete Wheel /\ssembly; Front
47. 738-0183 Shoulder Screw .50 x .21:3/8-16 634-0170A Rim Assembly*
48. 738-0347 Shoulder Spacer 734-0255 Valve*
49. 738-0826 Shoulder Screw 1/4-28 x .375 741-0487A FI. Bearing*
50. 741-0495 Flange Bearing 741-0706 FI. Bearing*
51.
52.
746-1089
746-1127 Choke Control
Deck Cable
104. 714-0115 Cotter Pin
' Not shown in illustration
