CRAFTSMAN 1800 PSI HIGH PRESSURE WASHER 580.761800
BRIGGS & STRATTON 4-CYCLE ENGINE 12F802-2407-E1
REF.
NO.
PART
NO. DESCRIPTION
REF.
NO.
PART
NO. DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
16
498571 Crankshaft
28
499423 Pin-Piston
34
262652 Valve-Intake
24
222698 Key-Flywheel
(Standard)
35
262224 Spring-Valve
25
499429 Piston Assembly
29
499424 Rod-Connecting
40
93312 Retainer-Valve
(Standard)
(Standard)
45
262204 Tappet-VSIve
26
499425 Ring Set
32
94699 Screw-Hex.
146
94388 Key-Timing
27
(Standard)
263190 Lock-Piston Pin
33
262651 Valve-Exhaust
741
262598 Gear-Timing
ir
Induded in Gasket Set-Part Number 497316.
• Included in Carburetor Kit-Part Number 498260.
♦ Included in Carburetor Gasket Set-Part Number 498261.
0 Included in Valve Overhaul Gasket Set-Part No. 498526.
Assemblies Include all narts shown In frames.
