KNOW YOUR DRILL PRESS
Spindle
pulley
Motor
pulley
Depth scale stop nuts Depth scale
\
pointer
Cord clamp
Belt
tension
knob
Depth scale
Feed stop rod
Depth stop
ON/OFF
switch w/key
Cover
Feed handle
Chuck
Support lock handle
Base
\
Bevel lock
Table
Fence backstop
Head lock
screw
Motor
Belt
tension
knob
Head lock
screw
Table crank
handle
Column support
