SAFETY LABEL
J
ROTATING BLADES CAL
SERIOUS INJURY OR DEATH
> DO NOT MOW WHEN CHILDREN OR OTHERS ,
ARE AROUND
> NEVER CARRY CHILDREN EVEN WITH
SLADE(S)OFF.
• LOOK DOWN AND BEHIND BEFORE
AND WHILE BACKING.
• MOWING IN REVERSE IS NOT RECOMMENDED.
A W A R N I N G
TO AVOID SERIOUS INJURY OR DEATH
GO UP AND DOWN SLOPES, NOT ACROSS.
AVOID SUDDEN TURNS.
DO NOT OPERATE THE UNIT WHERE IT COULD SUP M TIP.
IF MACHINE STOPS GOING UPHILL, STOP RUDE(S)
AND RACK DOWNHILL SLOWLY.
KEEP SAFETY DEVICES (GUARDS, SHIELDS, AND SWITCHES,
ETC.) IN PLACE AND WORKING.
REMOVE OBJECTS THAT COULD BE THROWN BY THE BLABE(S).
KNOW LOCATION AND FUNCTION OF ALL CONTROLS.
BE SURE BUDE(S) AND ENGINE ARE STOPPED BEFORE
PUCING HANDS OR FEET NEAR BUDE(S).
BEFORE LEAVING OPERATOR'S POSITION, DISENGAGE BLADE(S),
ENGAGE PARKING BRAKE, SHUT WF AND REMOVE KEY.
READ OPERATOR'S MANUAL
1. DISENGAGE BLADES/PTO, fPOlVER TAKE OFF}
2. ENGAGE THE TRACTOR’S PARKING BRAKE.
3. SET THROTTLE TO FAST “RABBIT" POSITION AND PULL CHOKE KNOB OUT.
4. TURN KEY TO START ENGINE. AFTER START RELEASE KEY & DEACTIVATE CHOKE.
OPERATING MODES
NORMAL MOWING
/ Y O U MUST DISENGAGE BLADES PTO. (POIVER TAKE OFFi BEFORE
' TRAVELING IN REVERSE.
________ CAUTION MODE
1. TURN KEY TO REVERSE CAUTION MODE POSITION.
2. DEPRESS REVERSE PUSH BUTTON. (RED INDICATOR LIGHT “ON”)
WHEN RED LIGHT IS “ON” MACHINE CAN BE OPERATED IN REVERSE
WITH MOWER BLADES ENGAGED.
mpommii mowing in reverse is not recommended .
3. AFTER RESUMING FORWARD OPERATION, RETURN KEY TO
“NORMAL MOWING” POSITION.
NOTE: IN BOTH modes , when operator leaves seat , engine will
STOP UNLESS PARKING BRAKE IS SET AND BLADES ARE DISENGAGED.
¡HOW TO operate !
BRAKE/CLUTCH
PEDAL
(LOCATED ON DRIVERS 1£FT)
SEAT ADJUSTMENT
(LOCATED ON DRIVERS RIGHTl
PULL HANDLE UP TO MOVE SEAT FORWARD
TO PUSH RIDER, PULL OUT BOTH RELEASE LEVERS PRESS THE FORWARD
(OR REVERSE) DRIVE PEDAL CONTINUE TO HOLD PEDAL WHILE PUSHING.
31 STEP© Important! Release Bath Rods
. Pull lever out so elbow passes through the large part of the keyhole slotJt. Press aod HOLD either the
. Move lever ioward to the small part of the keyhole slot so that the
forward or reverse drive
Ibow is locked agaiost the back of the hitch plate. pedal, cootioue to Hold pedal
Repeat to eogage the other release lever.___________ dowo while pushiog.
(LOCATIDOS
posmos I—._____ ^1___________ ^'
0
"w«D
TO REDUCE THE RISK OF INJURY, DO NOT
OPERATE UNLESS DISCHARGE COVER OR
GRASS CATCHER IS IN ITS PROPER PLACE.
IF DAMAGED, REPLACE IMMEDIATELY.
■7.VÍ-1
A
danger
^
®f«'OUS INJURY OR DEATH
AWAY FROM
1 l №,1 №. ts that can be thro «« Tf
KEEP HANDS and FEET AWAY
A DANGER
KEEP HANDS AND FEET AWAY.
DO
NOT OPERATE MOWER
UNLESS CHUTE DEFLECTOR
OR ENTIRE GRASS CATCHER IS
IN ITS PROPER PLACE.
ASSEMBLE CHUTE DEFLECTOR TO THIS UNIT BEFORE OPERATING.
A warning
SHIELD MISSING
DO NOT OPERATE.
