OPERATION
\
4
Q^l^cnQ
QCLaiLiQ
□ Cr^WCilD
______if T —
'"M
Figure 2
A
Systems Indicator Monitor/ Hour Meter
J
Deck Lift Lever
B
Throttle Control Lever
K
Cup Holder
C
Key Switch Module
L
Seat Adjustment Lever
D
Choke Control Knob
M
Fuel Fill Cap
E
PTC (Blade Engage)Control Knob
N
IVT Transmission Release levers
F
Parking Brake Lever
0
Fuel Level Window
G
Forward Control Pedal
P
Cargo Net
H
Reverse Control Pedal
Q
Hood Lift Notch
I
Brake Pedal
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator's position.
Meets ANSI Safety Standards
Craftsman Tractors conform to the safety standard of the American National Standards Institute (ANSI).
