PARTS LIS
I
J
Craftsman Revolution Model 247.28933
Ref. No.
Part No.
Description
1
.
918-04414
Steering Assembly, Synchro
2
.
631-04331
Wheel Assembly, Steering
3.
634-04415
Wheel Assembly, 15 x5 x
6
734-04347-0901
Tire, 15 x5 x
6
634-04104
Rim Assembly
737-0224
Grease Fitting
941-04137
Bearing
934-0255
Valve, Tubeless Air
4.
683-04439
Axle Assembly, RH
5.
683-04440
Axle Assembly, LH
6
.
647-04080A-0637
Rod, Fender Support
7.
683-04285-0637
Link, Steering, IVT
8
.
710-04006
Screw, Flex Wash, 5/16-18 x 2.0
9.
710-04187
Screw, Flex Wash, Hi/Lo, 1/4-15 x .5
10
.
710-04389
Screw, Flex Wash, 5/16-18 x 2.25
11
.
710-04484
Screw, Flex Wash, 5/16-18 x .75
12
.
710-04692
Screw, Flex Cap, 3/8-16 x 7.25 Gr5
13.
710-0513
Screw, Flex Cap Lock, 1/4-28 x .625
14.
710-0520
Screw, Flex Cap, 3/8-16 x 1.5 Gr5
15.
710-0528
Screw, Flex Cap, 5/16-18 x 1.25 Gr5
16.
710-0597
Screw, Flex Cap, 1/4-20 x 1.00
17.
710-0599
Screw, Flex Wash, 1/4-20 x .5
18.
710-0642
Screw, Flex Wash, 1/4-20 x .75
19.
710-0650
Screw, Flex Wash, 5/16-18 x .875
20
.
710-3015
Screw, Flex Cap, 1/4-20 x .75 Gr5
21
.
710-3119
Screw, Flex Cap Lock, 3/8-16 x .75
22
.
710-3144
Screw, Flex Cap, 3/8-16 x 2.0 Gr5
23.
710-3296
Screw, Flex Cap Lock, 1/4-20 x .75
24.
711-04472
Link, Drag
25.
711-04562
Shaft, Steering Pivot Gear
26.
711-04722
Pin, Clevis, .375 x .969 HT
27.
712-0312A
Nut, Jam, 3/8-24 LFI Thrd
28.
741-04280
Brg., Ball
29.
712-0375
Nut, Flex Lock, 3/8-16
30.
712-04063
Nut, Flex Insert Flange Lock, 5/16-18
31.
712-04064
Nut, Flex Insert Flange Lock, 1/4-20
32.
712-04065
Nut, Flex Insert Flange Lock, 3/16-16
33.
912-3001
Nut, Flex Jam, 3/8-24 Gr2
34.
913-04037
Link, Connecting
35.
914-0104
Pin, Internal Cotter
36.
714-04039
Pin, Cotter, 5/32 x 1.25
Ref. No.
Part No.
Description
37.
717-04274A
Gear, Spur, 12T
38.
717-04275A
Gear, Spur, RFI13T
39.
717-04282A
Gear, Spur, LFI 13T
40.
719-04170A
Axle, Pivot Bar
41.
719-04287-0637
Arm, Steering, LFI
42.
719-04288-0637
Arm, Steering, RFI
43.
723-04035
End, Ball Joint Rod
44.
723-04036
End, Ball Joint Rod, LH Thrd.
45.
738-1011A
Bolt, Shoulder, .5 x 2.23:3/8-16
46.
731-05476
Cover, Steering Gear, RH
47.
731-05618
Cover, Steering Gear, LH
48.
731-06825
Cap, Steering Wheel
49.
936-0185
Washer, Flat, .375 x .738.063
50.
736-0270
Washer, Bell, .265 x .75 x .062
51.
936-0300
Washer, Flat, .406 x .875 x .059
52.
736-0315
Washer, Flat, .76 x 1.5 x .12
53.
936-0452
Washer, Bell, .396 x 1.14 x .095
54.
736-0866
Washer, Flat, .755 x 1.92 x .060
55.
936-3004
Washer, Flat, .406 x .875 x .105
56.
736-3052
Washer, Flat, .406 x 1.0 x .105
57.
931-3020
Hub Cap
58.
937-3000
Fitting, Grease
59.
738-04189
Shaft, Steering, .625 x 17.281
60.
738-04240
Nut, Shoulder, .375 x .5
61.
747-04496
Rod, 3/8-24
X
14.4 Lg
62.
748-04139
Block, Steering Shaft
63.
750-04676
Spacer, .385 x .63 x .75
64.
750-04776
Spacer, .380 x .625 x .265
65.
736-04299
Washer, Flat, .281 x .50 x .04
66
.
750-04855
Spacer, .385 x .75 x 3.47
67.
783-04798-0637
Bracket, Steering Support, LH
68
.
783-04799-0637
Bracket, Steering Support, Upper
69.
783-05140-0637
Bracket, Steering Support, RH
70.
783-05184-0637
Plate, Base Cover, RH
71.
783-05185-0637
Plate, Base Cover, LH
72.
783-05956
Link, Cont., IVT
73.
783-05957
Bracket, IVT/Steering Adjustment
74.
783-05706
Bracket, Support Arm
75
710-04040
Scr, Shidr., .497 x .750
76
712-0376
Nut, 3/8-16
