Craftsman 247.775880 - Manual (Page 23)

SEARS CRAFTSMAN 8.5 H.P. ENGINE MODEL 143. 988503 FOR
CHIPPER-SHREDDER MODEL 247.775880
Key
No.
Part No.
185 34707
186 34667
200 34677
203 31342
204 651029
206 610973
207 33878
209 650821
215 35882
223 650378
224 27915A
238 28820
239 27272A
240 37104
242 33267
245 33268
245A 35881
250 33269A
251 650513
260 36250
261 650788
262 29747B
264A 650802
265 33272B
275 34185B
276 31588
277 650729
277A 651036
Description
Key
No.
Part No. Description
278 36908 Heat Shield Spacer
280 36799A Heat Shield
281 33013 Starter Bubble Cover
282 650760 Screw, 8-32 x 3/8’
285 35985B Starter Cup
287 29752 Nut & Lock Washer
290 30962 Fuel Line
292 26460 Fuel Line Clamp
298 650665 Screw, 1/4-15 X 3/4’
300 34186A Fuel Tank
301 36246 Fuel Cap
305 35554 Oil Fill Tube
307 35499 O Ring
308 35540 Fill Tube Clip
310 36205 Dipstick
325 29443 Wire Clip
327 35392 Starter Plug
339 35880 Spacer
340 34259 Fuel Tank Bracket
341 34258A Fuel Tank Bracket
342 30063 Screw, Torx T-30.1/4-20 x 1/2"
370G 35274 Oil Instruction Decal
370J 35703 Throttle Decal
380 640112 Carburetor (Incl. 184)
390 590746 Rewind Starter
400 36450B Gasket Set
416 34479A Spark arrester Kit
900 — Replacement Engine none
900 Replacement SB 756321,
Order 71-999
Intake Pipe
Governor Link
Control Bracket (Incl. 19,203
&204)
Compression Spring
Screw. TorxT-10, 5-40 x 7/16”
Terminal
Throttle Link
Screw, 10-32 X 1/2”
Control Knob
Screw, Torx T-30, 5/16-18 x 1-
1/8
Intake Pipe Gasket
Screw, 10-32 X 1/2”
Air Cleaner Gasket
Air Cleaner Bracket
Air Cleaner Bracket
Air Cleaner Filter
Air Cleaner Filter
Air Cleaner Cover
Wing Nut, 1/4-20
Blower Housing
Screw, 5/16-18 X 3/4’
Screw, Torx T-40, 5/16-24 x
21/32”
Screw, 1/4-20 x 5/8"
Cylinder Head cover
Muffler
Locking Plate
Screw. 5/16-18x3-3/16"
Screw, 5/16-18x3-31/32"
23
