Key
No
Part No Description
Key
No
Part No Description
— 770-1228A Owner’s Manual 49 726-0214 Push Cap 5/8” dia.
1 11480 Stop Washer 50 734-0255 Air Valve
2 681-0118 inlet Guide Assembly 51 750-0793 Chute Hinge Spacer
3 681-0144 Arm Bracket Assembly 52 712-3027 Hex Ctr. Lock Nut 1/4-20 Thd.
4 710-0542 Hex Flange Bolt: 5/16-18 x 53 714-0149B Internal Cotter Pin
8.375" (Gr.5)
55 720-0170 Hand Knob
5 710-0607 Hex Washer Head Self-Tap-
56 710-0805 Hex Bolt 5/16-18x1.5"
ping Screw: 5/16-18 x 0.5"
57 781-051 OB Shredder Frame
6 710-3256 Button-Head Screw 1/4-20 x
58 736-0366 Flat Washer 1.12 x .64 x .120
U.5
59 734-1845 Wheel Assembly
7 712-0429 Lock Nut: 5/16-18
61 736-0170 Special Lock Washer
8 712-3027 Hex Flange Lock Nut: 1/4-20
9 714-0104 Internal Cotter Pin
63 681-0117-0689 Flail Housing Ass'y. — Inner
65 710-0157 Hex Bolt 5/16-24 x .75” Lg.
10 715-0129 Spiral Pin
67 — Engine, Tecumseh 143.988503
11 726-0106 Cap Nut
68 781-0490 Chipper Blade
12 726-0135 Speed Cap Nut
69 712-0411 Hex Top Lock Nut 5/16-24
13 728-0175 Pop Rivet
(Gr. 5)
14 732-0546 Torsion Spring
70 736-0119 LockWasher 5/16" l.d.
15 732-0629 Hopper Door Spring
71 681-0030 Impeller assembly
16 735-0127 Rubber Washer
72 742-0571 Shredder Blade
17 735-0651 Hopper Flap
73 781-0457-0637 Shredder Screen
18 736-0119 Lock Washer
74 681-0094 Discharge Chute Assembly
19 738-0137A Shdr. Scr: .340 x .285 x 1/4-20
75 781-0735 Retaining Clip
20 738-0946 Shdr. Scr: .56 x .165 x 5/16-18
76 715-0166 Spring Roll Pin
21 747-0531A Rel. Rod: 5/16" dia.
78 710-1054 Flat Head Scr. 5/16-24 x .75"
22 747-0747 Hopper Door Rod
79 710-3008 Hex Bolt 5/16-18 X .75” (Gr. 5)
23 747-1124 Flap Retaining Rod
80 681-0004A-0689 Flail Housing Ass’y. — Outer
24 747-1125 Flap Retaining Ball
82 7100825 Hex Bolt 1/4-20 x 3.75"
25 781-0492A Hopper Pivot Door
83 726-0211 U Nut 5/16-18
26 781-0633 Chute Flap Strip
85 711-0835 Clevis Pin
27 781-0698 Hopper Lock Bracket
87 719-0329 Flail Blade
28 781-0715 Shredder Plate
88 711-0833B Clevis Pin
29 781-0752 Flap Mounting Bracket
89 710-1254 Hex Patch Bolt 3/8-24 x 2.25”
30 781-0754-0689 Upper Hopper
(Gr.8)
31 781-0755-0689 Lower Hopper
90 736-0217 Lock Washer 3/8”
32 738-0813 Shredder Axle
91 736-0247 Flat Washer .406” l.d, x 1.25”
33 731-1899 Chipper Chute 92 7320306 Compression Spring
37 710-0751 Hex Bolt 1/4-20 x .625 93 7300117 Flat Washer
38 736-0173 Flat Washer .28 l.d. x .74 O.d, 94 714-0104 Internal Cotter Pin
39 712-3027 Flanged Lock Nut 95 711-1304 Axle Shaft
40 749-1004 Chipper Chute Support 96 7300160 Flat Washer
41 710-0106 Hex Scr. 1/4-20 x .625 (Gr. 2) 97 734-1797 Complete Wheel: Grey
43 712-3010 Hex Nut 5/16-18Thd. (Gr.5) 98 7200299 Push Cap
44 736-0242 Bell Washer .345” l.d. x .88" 99 747-0982 Lock Rod
45 735-0249 Shredder Chute Flap 100 764-0501 Shredder Bag
48 681-0068-0689 Chipper Chute Assembly
