ENGINE PARTS
CRAFTSMAN 2500 PSI HIGH PRESSURE WASHER 919.678250
BRIGGS ENGINE MODEL #121432-0112-E1
529 @
21^
22
.
306
307
REF.
PART
NO. NO.
DESCRIPTION
REF.
PART
NO. NO.
DESCRIPTION
REF.
PART
NO. NO.
DESCRIPTION
1
690045(F)
Cylinder Assembly
17
692510
Bearing-Ball
306
692552
Shield-Cylinder
2
399269
Bushing
18
690047
Cover-Crankcase
307
690345
Screw-Hex.
3
692266
Seal-Oil
20
692550
Seal-Oil
529
692553
Grommet
12
692549
Gasket-Crankcase
21
692261
Cap-Oil Fill
1019
690035
Label Kit
15
691696
Plug-Oil
22
692551
Screw-Hex.
1058
273700
Owner’s Manual
20
