7
9T122-08 Module Specific Information
Token Ring Bridge Configuration (Screen 1)
The 9T122-08 Token Ring Bridge ConÞguration Screen 1 (Figure 2), provides basic
setup options for making a bridge operational in your network.
Figure 2. 9T122-08 Token Ring Bridge Configuration Screen 1
SmartSwitch 9000 LOCAL MANAGEMENT
Bridge Configuration
Module Name: 9T122-08 Firmware Revision: 01.08.07
Slot Number: 2 BOOTPROM Revision: 01.01.09
Bridge Address: 00-00-1D-01-03-04 Bridging Interfaces: 3
Bridge Number (hex): 1 Type of STA: [IEEE]
Bridge Priority Label (hex): 8000 Novell Xlat: [NONE]
Bridge Path Cost (hex): 0000000A
Interface # MAC/Local Address Bridge State Status
1 (FNB) 00-00-B8-80-C0-A0 forwarding [ENABLED]
2 (TR1) 00-00-B8-80-C0-60 forwarding [ENABLED]
3 (TR2) 00-00-B8-80-C0-E0 forwarding [ENABLED]
SAVE INTERFACE CONFIGURATION RETURN
To modify a non-toggle Þeld on this screen, use the arrow keys to highlight the
Þeld, then press the Enter key. Now you can modify the Þeld.
NOTE
