Connecting outdoor
antennas
Connect the outdoor nntenn
reception.
FM antenna
Connect the optional FM outdoor antenna.
You can also use the TV antenna instead.
Jack type ®
Screw clamp
Ground wire (not supplied)
Jack type ®
lEC standard socket
connector
Screw clamp
AM antenna
Connect a 6- to l.S- meter (20- to 5*0- teet)
insulated wire t*.* the AM antenna terminal.
Leas e the supplied AM loop antenna
crinnected.
Jack type ®
Insulated wire
Screw clamp
Jack type (
Important
If you connect an outdoor antenna, ground
from
rh
terminal above the SPEAKER jacks
with the screw clamp. To prevent a gas
explosion, do not cormect the ground wire to
a gas pipe.
Ground wire (not supplied)
8
