Hooking Up the Audio Components

AC power cord

(fi

(/I

Required cords

Audio connecting cords (2) (supplied)

When connecting an audio connecting cord, be sure to match the
color-coded pins to the appropriate jacks: white (left) to white
and red (right) to red.

White (L)

Red (R)

White (L)

Red (R)

Optical cable (1) (supplied)

• When connecting an optical cable, take the caps off the

connectors and insert the cable plugs straight in until they click
into place.

• Do not bend or tie the optical cable.

Things you should keep in mind whiie

hooking up the system

• Turn off the power to all components before making

any connections.

• Do not connect any AC power cord until all the

connections are completed.

• Be sure the connections are firm to prevent hum and

noise.

Jacks (connectors) for connecting audio
components

Oli E

3 iiiiiP'

Connect

' To the

Amplifiers

LINE (ANALOG) IN / OUT jacks

Digital amplifiers, DAT

DIGITALIN connector

decks, another MD deck, CD
players, or DBS tuners
