Connections
Use the connecting cord and the adaptor supplied for the connections below.
To connect the stereo mini
jack of the audio equipment
to headphone output or line output
i
To connect the stereo phone
jack of the audio equipment
___________________________ X
a
im
fa c^3o|
•
1 » 1 »
•«» • • O
CD player, cassette-deck, etc.
to headphone jack
Plug adaptor (supplied)
to INPUT 1
Connecting cord (supplied)
Use the connecting cords and the adaptor (sold separately) for the connections below.
To connect the monaural mini
jack of the audio equipment
TV monitor, tape recorder, etc.
to earphone jack (monaural)
Plug adaptor
PC-236MS
(sold separately)
To connect the phono outputs
to INPUT 1 on the front
------------------------
cm
|0 =o|
LI 1 J-IJ .
•• • • O
CD player, cassette-deck, video deck, etc.
to line outputs
Connecting cord
RK-G129
(soid separately)
to INPUT 1
•To connect the stereo mini jack output to INPUT on the rear,
use also the connecting cord RK-G129 (soid separately).
