Connections
Notes on Connections
•
Do not connect the power cord to an AC outlet nor
press the POWER switch before accomplishing all other
connections.
• The cable connectors should be fully inserted into the
jacks. Loose connection may cause hum and noise.
Jacks and plugs of the connecting cord are color-
coded as follows:
Red jacks and plugs: For the right channel of audio
signals
White jacks and plugs: For the left channel of audio
signals
Yellow jacks and plugs: For video signals
Connecting Audio Equipment
O FM antenna
Monitor TV or an amplifier
for center speakers
o
Front speaker system
(A speakers)
O Center speaker © Rsar speaker
system
system
0 AM antenna
DRLC wireless remote
control receiver
(See page 32
OUT
(O)
©Front speaker
system
(B speakers)
6
