То charge a battery pack
Befofe using a Danary раск, make sure to charge it first even
supplied NP-55H Dattery раек, optional NP-66H, NP-77HD a
on page 10. are avaiiaole.
Use Ihe suppliefl AC-SIO AC power aaaptor to charge a battery pack.
1 Plug in №• AC power adaptor to a wall outlet.
The POWER lamp (green) on the AC-St 0 (ignis up and the power tu
2 Inatall the battery pack in the AC-SIO.
Align me flat side of the battery pack with the line on the AC-St 0. Then push down and slide tne
battery pack m the direction of the arrow. The REFRESH lamp (red) lights up first and then it goes
out. When the CHARGE lamp (orange) lights up, battery charging begins When the battery is
charged, the CHARGE lamp goes out Unplug the AC power adaptor and the POWER larhp goes
out. (Refer to the instructions provided tor the AC-StO as well.)________ __________________________
NP-eSH NP-66H NP-77H NP-77HD
(supplied)
70 mm. 100 mm. 140 ГТ11П. 140 mm.
(Approx, mnjiss using AC-SIO)
• The battery pack cannot be charged when using the AC power adaptor is used to operate the unit
• An NP-S5H. NP-66H. NP-77HD or NP-77H battery pack can also be charged with the BC-StO or BC-77
battery charger.
To anach a battery pack to this unit
Align the upper side edge of the battery with the white line prinied on the video recorder/moniior so
that the slots of the battery are positioned over the tabs of the battery mounting surface, and slide the
battery pack while pressing it
To cheek the remaining battery capacity
When a battery pack i$ installed, press DISPLAY to show on th
I as well as other indications (see page 7 for other indications)
I To cancel this display, press DISPLAY again.
• screen the remaining battery capacity
A fullycharged battery pack laatt lor:
Playback Approx. 70 m
Recording I Аррюх. 70 m
Approx. 106 m
Approx. 105 rn
Approx. 140 m
Approx. 140 m
; Approx. 140 m
I Approx. 140 m
I To remove the battery pack
j
While slidirtg the ВАТТ release knob m the direction ot the ai
I
illustrated
w, slide out (he battery pack a:
Note
It you use the NP-77HD battery pack which has the battery hte indicator, the remaining battery capacity
intlicateO on tne LCD may be different trom that indicated by the NP-77HD battery pack. The indicator c
the NP-77HD battery pack is more accurate.
