AC-S1Q
Power consumption
Power requirements
Output voltage
Battery onarge terminal:
Operating temperature
Storage temperature
Dimensions
Weight
Design and specifications are suOiect to change without notice.
List of HooofmiMndocI Accoooortoo-
20 W
100-240 VAC, 50/60 Hz
DC OUT- 7.5 V. t .6 A in operating mode
10 V. 1.3 A in charge mode
O’C to 40°C (32 F to 1(M=F>
-20°C to
*SOV M F to )4£>-'F)
Approx, 72 X 39 X 141 mm (w/h/d)
(2'/e X t’/.6 X 5V« inchest including protecting parts and controls
Approx. 330g (12oz.)
I NP-77HO, NP-77H, Or NP-66H
lC-SlOoreC-77
Car Battery charger
VMC-710M7720M (1 m/2 m) 23, 26. 27, 26
If you have a problem with this unit, first check the power supply source, then go through the list below
Delore calling the Sony service facility Should the problem persist, consult your Sony service facility.
Symptom PoMttM eausM шпО/ог comctloM
The unit does not work • The battery pack is not attached.
even though the • The battery pack is exhausted.
POWER switch IS Charge it (page 121
turned on. • AC power adaptor or car battery cord is disconnected.
1
&
Power turns otf * The battery pack is exhausted.
automatically during
operation.
The battery pack is • The temperature is too low
quickly discharged. • The battery pack is worn out.
• The battery pack has not been charged tuHy
The playback picture is • The video heads may be contaminated. Clean me heads using the
not dear Sony V8-25CLH cleaning cassette (not supphed).
? • The video heads may be damaged.
Have the video heads replaced with new ones.
1 Recording cannot be • The safety tab on the cassette is slid out to expose the red mark
• Moisture condensation has occurred.
• The tape is at its end.
1 • A cassette is not inserted.
i
The cassette cannot be • Moisture condensation has occurred
Ù, e/eated. • No power IS supplied to the unit.
• The battery pack is exhausted
Use a fully charged battery, (page 12)
The picture does not
appear. * Incorporated flouresceni tube is worn out.
u The picture appears but ♦ Adjust the volume.
no sound IS heard • Disconnected the earphones.
L_
No color • Adjust "COLOR" on the menu screen (page 2t).
