Samsung 430 User Manual
Page 5
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
See separate guide for installing the stand.
O
Guide Stand (1EA)
Follow the steps below to connect the TV to the stand.
x4 (M4XL12)
x4 (M4XL8)
Screws iSETAj
w
S
a>
CL
Top View
(M4XL12) t
ATTENTION
0#0
DO NOT USE DO NOT USE DO NOT USE
CHEMICALS GREASE
OIL
1. Connect the Guide Stand to the Stand using four screws (M4 X L12) as shown
(Correct assembly)
[K.
2. With your TV upright, connect the TV to the Stand.
NOTE
• Make sure to distinguish between the front and back of the Stand and Guide Stand when assembling them.
• Make sure that at least two people lift and move the POP TV.
/K Do not insert your fingers into the stand base slot of the TV when installing the stand base.
Engish 5
