Identifying the Parts
>
Q.
Q.
ilTl
Power zoom lever
(p.l4)
Hi EJECT switch (p.lO)
Ul LANC
C
control jack
C stands for Local Application Control
Bus System. The C control jack is used for
controlling the tape transport of video
equipment and peripherals connected to it.
This jack has the same function as the jack
indicated as CONTROL L or REMOTE.
H Cassette compartment (p.lO)
iH RFU DC OUT (RFU adaptor DC output)
jack (p.l8)
Grip strap (p.l6)
D (headphones) jack (p.20)
EDITSEARCH button
(p.l7)
LASER LINK button
(p.l9)
S VIDEO jack
(p.l8,44)
MIC jack (PLUG IN POWER)
Connect an external microphone (not
supplied). This jack also accepts a "plug-
in-power" microphone.
VIDEO/AUDIO jacks
(p.l8, 44)
63
