Specifications
Video recording system
Four rotary heads, Helical
scanning system (separate
SP/LP heads)
Audio recording system
Rotary heads, FM system
Video signal
NTSC color, EIA standards
Usable cassette
8mm video format cassette
(Hi8 or standard 8)
Recording / Playback time
(using 120 min. cassette)
SP mode: 2 hours
LPmode: 4 hours
Fastforward/rewind time (using
120 min. cadette)
Approx. 5 min.
Image device
CCD (Charge Coupled Device)
Viewfinder
Electronic viewfinder (Color)
Lens
Combined power zoom lens
Filter diameter 1 Vi6 in. (37 mm)
15x (Optical)
30x (Digital)
Focal distance
Vi6 - 2 Vs in. (4.1 - 61.5 mm)
1 Ve - 27 Ve in. (47 - 705 mm)
when converted to a 35 mm still
camera
Color temperature
Auto
Minimum illumination
2 lux (F 1.4)
Illumination range
2 lux to 100,000 lux
Recommended illumination
More than 100 lux
liriput and output
4XKin»ctors
S video input/output
4-pin mini DIN
Luminance signal; 1 Vp-p, 75
ohms, unbalanced, sync negative
Chrominance signal: 0.286 Vp-p,
75 ohm, unbalanced
Video input/output
Phono jack, 1 Vp-p, 75 ohm,
unbalanced, sync negative
Audio input/output
Phono jacks (2: stereo L and R)
327 mV, (at output impedance
47 kilohm) impedance lesaihan
2.2 kilohm
RFU DC OUT
Special minijack, DC 5 V
Headphone jack
Stereo minijack
LANC control jack
Stereo mini-minijack (0 2.5 nnm)
MIC jack
Minijack, 0.388 mV low
impedance with 2.5 to 3.0 V DC,
output impedance 6.8 kilohm
(0
3.5 mm)
Stereo type
Intelligent accessory shoe
8-pin connector
LASER LINK
Video/audio: IR space
transmission system according to
EIAJ (Electric Industries
Association of Japan) standards
Audio carrier wave:
Lch4.3MHz
R ch 4.8 MHz
'cenVal
Power requirements
7.2 V (battery pack)
8.4 V (AC power adaptor)
Average power consumption
3.5 W during camera recording
Operating temperature
32°F to 104°F (0°C to 40X)
Storage temperature
-4°F to +140°F (-20°C to +60°C)
Dimensions (Approx.)
4 V« X 4 ’/4 x 7 Vs in.
(108 X 107 x 178 mm) (w/h/d)
Mass (Approx.).
1 lb 11 oz (770 g) excluding the
battery pack, lithium battery,
cassette and shoulder strap
2 lb (920 g) iiKluding the battery
pack NP-F330, lithium battery
CR2025, cassette and shoulder
strap
Microphone
Stereo type
Supplied accessories
See page 5.
Power requirements
110-240 VAC, 50/60 Hz
Power consumption
25 W
Output voltage
DC OUT: 8.4 V, 1.9 A in operating
mode
Battery charge terminal: 8.4 V, 1.4
A in charge mode
Application
Sony battery packs NP-F330,
NP-F530, NP-F730, NP-F930
lithium ion type
Operating temperature
32°F to 104^F (0°C to 40°C)
Storage temperature
to +140°F (-20°C to +60°C)
Dimensions (Approx.)
3 V
4 X 1 *^/i6 x 6 '/2 in.
(81 X 45 X 163 mm) (w/h/d)
including projecting parts and
controls
Mass (Approx.)
1 lb 3 oz (560 g)
Design and specifications are
subject to change without notice.
61
