ITBR001-328 www.twobros.com 2013 Kawasaki ZX-6R - 4
Figur
e
D
Figur
e
E
9. Plug the JBP wiring harness in-line of the fuel injector and the stock wiring harness (Fig. D).
The ORANGE colored wires of the JBP go to the #1 (LEFT) cylinder.
10. Unplug the stock wiring harness from the primary Throttle Position Sensor (Fig. E).
The TPS connector is located on the right side of the throttle bodies. This is the
BLACK connector, do NOT connect to the GREY connector.
11. Plug the JBP wiring harness in-line of the stock wiring harness and TPS (Fig. F).
12. Reinstall the fuel tank.
Stk connector
JBP connector
JBP connector
