ITBR001-328 www.twobros.com 2013 Kawasaki ZX-6R - 3
Figur
e
A
Figur
e
B
Figur
e
C
5. Using the supplied Velcro, secure the JBP in the tail section (Fig. B).
Be sure to clean both surfaces with the alcohol swab before attaching
6. Route the JBP harness down the left hand side of the frame going towards the throttle
bodies.
7. Attach the ground wire of the JBP to the negative side of the battery.
8. Unplug the stock wiring harness from each of the fuel injectors (Fig. C).
Gr
ound
1. Remove the main seat and the passenger seat.
2. Remove the plastic covers from both sides of the fuel tank.
3. Remove the fuel tank.
4. Remove the airbox.
The bottom clamps of the airbox can be loosened by accessing them throug the
hole in the frame (Fig. A).
