Two Brothers Racing Kawasaki Versys650 - Manual (Page 3)

ITBR001-142 2006-10 Kawasaki ZX650, ER6n, and Versys - 3
Fi
gu
re
A
Fi
gur
e B
Fi
gu
re
C
Juice Box Pro
harness
remove remove
The ignition must be turned OFF before installation.
1 Remove the seat.
2 Remove the fuel tank.
3 Lay the Juice Box Pro in the tail section and route the harness towards the front of
the bike.
4 Route the Juice Box Pro harness under the frame crossover as shown in Figure A.
5 Route the Juice Box Pro harness under the fuel tank bracket as shown in Figure B.
6 Remove the bolts in the air box lid as shown in Figure C.
