Two Brothers Racing Kawasaki Ninja 650 - Manual (Page 5)

ITBR001-318 www.twobros.com 2012 Kawasaki EX650 - 5
12. Locate the Throttle Position Sensor (TPS) connector as shown in Figure G.
The TPS connector is located on the left hand side of the throttle bodies.
13. Unplug the TPS connector from the throttle bodies.
14. Attach the connectors from the Juice Box Pro to the TPS and the stock wiring
harness.
15. Attach the ground wire from the Juice Box Pro to the negative side of the battery
as shown in Figure H.
16. Reinstall the air box.
17. Reinstall the fuel tank.
18. Reinstall the seat.
FIG
.G
FIG
.H
FIG
.I
19. Using the stock rubber band, secure the Juice Box Pro in the tail section.
ground
