Taylor-Wharton LABS Series User Manual
Page 14
12
LABS
LABS 80K
LABS 94K
LABS 20K
LABS 38K
LABS 40K
Typical
Cassette
Design
Part Number
Capacity
Frames
Cassettes
LABS 20K
420
84
420
LABS 38K
690
138
690
LABS 40K
830
166
830
LABS 80K
1610
322
1610
LABS 94K*
1932
322
1932
Figure 8.0 Rack Arrangement for 500 ml Cassettes
*LABS 94K use a 6-level rack. All other units utilize a 5-level rack configuration.
Figure 8.0
Rack Arrangement
for 500 ml Cassettes
