Taylor-Wharton LABS Series User Manual
Page 13
Figure 7.0
Rack Arrangements
for 250 ml Cassettes
11
LABS
LABS 80K
LABS 94K
LABS 20K
LABS 38K
LABS 40K
Typical
Cassette
Design
Part Number
Capacity
Frames
Cassettes
LABS 20K
500
100
500
LABS 38K
900
180
900
LABS 40K
990
198
990
LABS 80K
1920
384
1920
LABS 94K*
2304
384
2304
Figure 7.0 Rack Arrangements for 250 ml Cassettes
*LABS 94K use a 6-level rack. All other units utilize a 5-level rack configuration.
