1
Names of Parts and Their Functions
Connecting the Strap
It is possible to attach a commercially available strap.
See the illustration below.
Attaching the Screen Protect Sheet
Follow the procedure below to attach the optional screen protect sheet (HA-
C90PS5B).
Do not press strongly on the LCD screen when attaching the screen
protect sheet. Doing so may break the screen.
q Before you attach the protect sheet to the LCD screen, hold it up to the LCD
screen to check the positioning.
w Use a lens-cleaning cloth to clean off the LCD screen.
e Pull the clear film (the triangle indicates adhesive surface) in the direction of the
arrow about half way off of the protect sheet as shown in Fig. 2. It is easy to
peel off if you use the pad of your thumb.
Note: Do not let your fingers touch the adhesive surface when you are doing this.
Important
Fig. 1
Fig. 2
