DOCUMENT 1025
REV. H
Instruction Manual
AGS-LED
858 LED Series
Sizes 1, 2, 3, 4 and 5
66
DESCRIPTION
PART
NUMBER
USED ON
Frangible Coupling 62245-1
62245-2
62245-3
62245-4 Size 1
Size 2
Size 3 & 5
Size 4
Power Supply PCB (located
inside circuit box) 62277 All Sizes
Heatsink/LED Assembly
(located inside sign housing) 62288 All Sizes
Filter PCB (located inside
circuit box) 62279 All Sizes
Bridge Rectifier and Thermal
Pad Replacement Kit (located
inside circuit box) 62314 All Sizes
Sign Face Panel (w/Legend) 62290-X Contact Factory with legend
information
Sign Panel, Black 60668-X Contact Factory with sign size
and number of modules
LED Array to LED array input
wire, white 62278-1(48”)
62278-2(12”)
62278-3(6”) All sizes
All sizes except size 3
1,2,3,4 module and size 5
All sizes except size 1 & 2
1,2,3,4 module and size 4
Last LED array to power
supply PCB CN9, return wire,
black 62317-1(67”)
62317-2(85”)
62317-3(105”)
62317-4(92”)
62317-5(120”)
62317-6(144”)
62317-7(131”)
62317-8(162”)
62317-9(192”)
62317-10(158”)
62317-11(196”)
62317-12(232”)
62317-13(118”) Size 1, 1 module
Size 2, 1 module
Size 3 & 5, 1 module
Size 1, 2 module
Size 2, 2 module
Size 3, 2 module
Size 1, 3 module
Size 2, 3 module
Size 3, 3 module
Size 1, 4 module
Size 2, 4 module
Size 3, 4 module
Size 4 DMS
Table 13. Parts List
