AGS-LED
858 LED Series
Sizes 1, 2, 3, 4 and 5
65
D4
(RED)
D7 (RED)
Optional
LED (RED)
D11
(GRN)
D29
(GRN)
Fault
OFF
ON
Blink
ON
ON
Input Current and/or Input
Voltage outside specified
operating range.
ON
OFF
Blink
ON
ON
Output Voltage out of
specified range.
ON
ON
Blink
ON
ON
Output Current and/or
Output Voltage out of
specified operating range.
X
X
X
ON
OFF
+3.3V Power Supply Failure
X
X
X
OFF
OFF
+15V and/or +3.3V Power
Supply Failure
Note: X = Don’t Care
Table 12. Power Supply Faults
