DOCUMENT 1025
REV. H
Instruction Manual
AGS-LED
858 LED Series
Sizes 1, 2, 3, 4 and 5
61
Style
Sign Size
#
Modules
CCR
type
CCHALP
Sign VA
(Primary
Isolation
Xfrmr@
6.6A)
CCHALP
Sign
Watts
(Primary
Isolation
Xfrmr @
6.6A)
CCHALP
Power
Factor
(Primary
Isolation
Xfrmr)
CCHALP
Sign VA
(Secondary
Isolation
Xfrmr@
6.6A)
CCHALP
Sign
Watts
(Secondary
Isolation
Xfrmr @
6.6A)
CCHALP
Power
Factor
(Secondary
Isolation
Xfrmr)
CCHALP
Isolation
Transformer
Type
2
1
1
Series
127
68
0.54
53
53
0.98
200W
2
1
2
Series
132
76
0.58
62
60
0.97
200W
2
1
3
Series
134
83
0.61
67
66
0.96
200W
2
1
4
Series
139
91
0.65
77
73
0.95
200W
2
2
1
Series
128
71
0.55
56
54
0.98
200W
2
2
2
Series
131
76
0.58
62
60
0.97
200W
2
2
3
Series
136
84
0.63
72
68
0.96
200W
2
2
4
Series
138
90
0.66
77
73
0.96
200W
2
3
1
Series
132
77
0.59
62
61
0.97
200W
2
3
2
Series
139
91
0.66
76
74
0.95
200W
2
3
3
Series
149
108
0.72
95
91
0.96
200W
2
3
4
Series
158
118
0.76
105
101
0.96
200W
2
4
2
Series
143
98
0.68
85
81
0.96
200W
Table 6. AGS 858 LED Sign Style 2 VA Load & Matching Isolation Transformer (Series)
