AGS-LED
858 LED Series
Sizes 1, 2, 3, 4 and 5
59
Style
Sign
Size
#
Modules
CCR
type
CCHALP
Sign VA
(Primary
Isolation
Xfrmr@
6.6A)
CCHALP
Sign
Watts
(Primary
Isolation
Xfrmr @
6.6A)
CCHALP
Power
Factor
(Primary
Isolation
Xfrmr)
CCHALP
Sign VA
(Secondary
Isolation
Xfrmr@
6.6A)
CCHALP
Sign
Watts
(Secondary
Isolation
Xfrmr @
6.6A)
CCHALP
Power
Factor
(Secondary
Isolation
Xfrmr)
CCHALP
Isolation
Transformer
Type
3
1
1
Ferro
72
71
0.98
60
59
0.99
100W
3
1
2
Ferro
80
78
0.98
68
67
0.99
100W
3
1
3
Ferro
85
83
0.98
73
72
0.98
100W
3
1
4
Ferro
96
94
0.97
83
82
0.97
100W
3
2
1
Ferro
72
71
0.98
60
59
0.99
100W
3
2
2
Ferro
78
76
0.98
66
65
0.99
100W
3
2
3
Ferro
88
86
0.97
76
73
0.97
100W
3
2
4
Ferro
105
99
0.94
85
82
0.97
200W
3
3
1
Ferro
80
78
0.98
68
67
0.99
100W
3
3
2
Ferro
97
94
0.98
84
83
0.98
100W
3
3
3
Ferro
116
111
0.95
96
93
0.97
200W
3
3
4
Ferro
136
131
0.96
115
111
0.97
200W
3
4
2
Ferro
114
110
0.96
93
90
0.98
200W
Table 4. AGS 858 LED Sign Style 3 VA Load & Matching Isolation Transformer (Ferro)
