Router T

able

for the Craftsman

APPENDIX

Plan for

HIT

ACHI TR12

Router

4 holes for
M5 M/C
screws

21mm

21mm

77mm

77mm

77mm

21mm

21mm

77mm

FRONT OF CRT TABLE

Position of

Router Handle

Position of

Router Handle

C

C
