PARTS
VARIABLE MANUALLY-CONTROLLED SEASONAL OAK MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts, below.
KEY
NO. PART NUMBER
DESCRIPTION QTY. CRL2718PA CRL2718NA CRL3124PA CRL3124NA
1 113551-01 113551-01 113551-02 113551-02 Back Log (#1) 1
2 113552-01 113552-01 113552-02 113552-02 Front Log (#2) 1
3A 113553-01 113553-01 113553-01 113553-01 Left Crossover Log (#3A) 1
3B 113554-01 113554-01 113554-01 113554-01 Right Crossover Log (#3B) 1
4 ** ** ** ** Painted Base Assy 1
5 102844-01 102844-01 102844-01 102844-01 Lower Bracket 1
6 M11084-38 M11084-38 M11084-38 M11084-38 Screw, Hex Head (#8-18 x 0.38) 8
7 098867-10 098867-14 098867-10 098867-14 Gas Regulator 1
8 111331-04 111331-04 111331-04 111331-04 Outlet Burner Tube 1
9 102798-01 102798-01 102798-01 102798-01 Inlet Tube 1
10 099056-21 099056-20 099056-19 099056-18 Burner Orifice Injector 1
11 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1
12 102963-02 102963-02 102773-03 102773-03 Burner 1
13 119583-01 102568-07 119583-01 102568-07 Control Valve 1
14 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1
15 098354-01 098354-01 098354-01 098354-01 Control Knob 1
16 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1
17 098249-01 098249-01 098249-01 098249-01 Nut, M5 2
18 099387-08 099387-08 099387-08 099387-08 Pilot Tube 1
19 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
20 PP224 PP224 PP224 PP224 ODS Pilot 1
21 PP229 PP229 PP229 PP229 Hex Head Plug, 1/8" NPT 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
101055-02 101055-02 101055-02 101055-02 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 100639-01 Caution Decal 1
101449-04 101449-04 101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 GA6060 Lava Rock 1
** Not a field replaceable part.
REPLACEMENT PARTS
Note: Use only original replacement parts.
This will protect your warranty coverage for
parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product. If
they can’t supply original replacement part(s),
call DESA Heating, LLC at 1-866-672-6040.
When calling DESA Heating, LLC, have ready:
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• purchase date
Usually, we will ask you to return the part to
the factory.
PARTS NOT UNDER WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), either contact your nearest Parts
Central (see page 31) or call DESA Heating,
LLC at 1-866-672-6040 for referral informa-
tion. A list of authorized dealers can be found
by visiting www.desatech.com.
When calling DESA Heating, LLC, have ready:
• model and serial numbers of your heater
• the replacement part number
