PARTS
THERMOSTATICALLY-CONTROLLED BILTMORE SPLIT OAK MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 35 of this manual
KEY
NO. PART NO.
DESCRIPTION
QTY.
1
111340-02
Front Log (#1)
•
•
1
111340-03
Front Log (#1)
1
2
111341-02
Middle Log (#2)
•
•
1
111341-03
Middle Log (#2)
1
3
111342-02
Back Log (#3)
•
•
1
111342-03
Back Log (#3)
1
4
111343-02
Left Back Crossover Log (#4)
•
•
1
111343-03
Left Back Crossover Log (#4)
1
5
111344-01
Left Top Crossover Log (#5)
•
•
1
111344-02
Left Top Crossover Log (#5)
1
6
111345-02
Right Bottom Crossover Log (#6)
•
•
•
•
1
7
099211-01
Hex Screw, 10-16 x 2.50
•
•
•
•
2
8
102844-01 Lower Bracket
•
•
1
102844-02 Lower Bracket
•
•
1
9
**
Painted Base Assembly
•
•
•
•
1
10 098867-10 Gas Regulator
•
•
1
098867-14 Gas Regulator
•
•
1
11 102810-03 Inlet Tube
•
•
•
•
1
12 102983-05 Outlet Burner Tube
•
•
1
102983-06 Outlet Burner Tube
•
•
1
13 099056-16 Burner Orifice Injector
•
1
099056-17 Burner Orifice Injector
•
1
099056-19 Burner Orifice Injector
•
1
099056-26 Burner Orifice Injector
•
1
14 111124-01
Burner Retainer Spring
•
•
1
15 102772-01 Burner
•
•
1
102980-01 Burner
•
•
1
16 101329-19 Thermostat Gas Valve Assembly
•
1
101329-20 Thermostat Gas Valve Assembly
•
1
101329-21 Thermostat Gas Valve Assembly
•
1
101329-22 Thermostat Gas Valve Assembly
•
1
17 102979-01 Thermostat Bracket
•
•
1
102979-02 Thermostat Bracket
•
•
1
18 098544-01 Thermostat Clip
•
•
•
•
1
19 102445-01 Piezo Ignitor
•
•
•
•
1
20 099387-09 Pilot Tube
•
•
•
•
1
21 098271-10 Ignitor Cable
•
•
•
•
1
22 PP224
ODS Pilot
•
•
•
•
1
23 M11084-38 Hex Screw, #8-18 x 0.38
•
•
•
•
12
24 098249-01 Nut, M5
•
•
•
•
2
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate
•
•
•
•
1
101054-01 Lighting Instructions Plate
•
•
•
•
1
100565-01 Warning Plate Fastener
•
•
•
•
1
100639-01 Caution Decal
•
•
•
•
1
101137-02
Hardware Kit
•
•
•
•
1
GA6060
Lava Rock
•
•
•
•
1
** Not a field replaceable part.
CCL3924PT
A
CCL3018PT
A
CCL3924NT
A
CCL3018NT
A
