Removing and Replacing Parts

4-7

'ULYHV

Figure 4-6 shows an example of drive hardware that can be installed in the
computer. Refer to this figure when you perform any of the procedures in the
following subsections.

)LJXUH 'ULYH +DUGZDUH

back

power supply

diskette/tape drive
interface cable

DC power cable

internal
hard-disk drive

3.5-inch diskette drive

EIDE cable

DSKT connector

primary EIDE
interface
connector (IDE1)

secondary EIDE
interface
connector (IDE2)

5.25-inch drive
bay and bracket
