1-20 Dell OptiPlex E1 Managed PC Service Manual
3RUWV DQG &RQQHFWRUV FRQWLQXHG
Microphone
(optional) . . . . . . . . . . . .
89-mVrms (maximum); mono
Line-out (optional) . . . . . 1.4-Vrms (maximum); stereo (at 32 ohms
minimum impedance)
Internally accessible:
Primary EIDE
hard-disk drive . . . . . . . .
40-pin connector on PCI local bus
Secondary EIDE
hard-disk drive . . . . . . . .
40-pin connector on PCI local bus
Diskette drive . . . . . . . . . 34-pin connector
CD-ROM drive audio
interface cable . . . . . . .
4-pin connector
ATI multimedia . . . . . . . . 40-pin connector
TAPI . . . . . . . . . . . . . . . . 4-pin connector
.H\ &RPELQDWLRQV
. . . . . . . . . . . restarts (reboots) the system
. . . . . . . . . . . . . . . . . . starts System Setup program (during the
POST only)
<\> . . . . . . . . . . toggles microprocessor speeds on 101-key
keyboard (in MS-DOS
®
real mode only)
<#> . . . . . . . . . toggles microprocessor speeds on 102-key
keyboard (in MS-DOS real mode only)
&RQWUROV DQG ,QGLFDWRUV
Reset control . . . . . . . . . . . . push button
Power control. . . . . . . . . . . . push button
Power indicator . . . . . . . . . . green LED in normal operation; flashing
green LED in sleep state
green LED on riser board
Diskette-drive access
indicator . . . . . . . . . . . . . . . .
green LED
Hard-disk drive access
indicator . . . . . . . . . . . . . . . .
green LED
Link integrity indicator . . . . . green LED
Activity indicator . . . . . . . . . yellow LED
7DEOH 7HFKQLFDO 6SHFLILFDWLRQV FRQWLQXHG
