Keyboard

Keyboard

For more information about the keyboard, see "Using the Keyboard and

Touchpad" in your Owner’s Manual.

CAUTION:

Before you begin any of the procedures in this section, follow the

safety instructions in the

Product Information Guide.

NOTICE:

To avoid electrostatic discharge, ground yourself by using a wrist

grounding strap or by periodically touching an unpainted metal surface (such as a

connector on the back of the computer).

NOTICE:

To help prevent damage to the system board, you must remove the battery

from the battery bay before you begin working inside the computer.

Removing the Keyboard

1 Follow the procedures in "Before You Begin" on page 9.
2 Remove the Center Control Cover and Hinge Covers (see "Removing the

3 Remove the two M2.5 x 5-mm screws at the top of the keyboard.

NOTICE:

The keycaps on the keyboard are fragile, easily dislodged, and time-

consuming to replace. Be careful when removing and handling the keyboard.

4 Carefully slide the keyboard toward the back of the computer.

NOTICE:

Be extremely careful when removing and handling the keyboard. Failure

to do so could result in scratching the display panel.
