32 Keyboard
CAUTION: Exercise caution while lifting up the keyboard to avoid pulling the
keyboard connector from the system board forcefully.
6 Carefully lift the keyboard and slide the keyboard tabs out of the slots on
the palm-rest assembly.
7 Turn the keyboard over and place the keyboard on the palm-rest assembly.
8 Lift the connector latches and disconnect the keyboard cable and the
keyboard-backlight cable from the connectors on the system board.
NOTE: The keyboard-backlight cable is available only if you purchased a back-lit
keyboard.
1 tabs (4) 2 plastic scribe
3 keyboard 4 palm-rest assembly
1
2
4
3
