Your Dell Projector

7

About Your Projector

1

IR receivers

2

Lamp cover

3

Camera

4

10 W speaker

5

Lens

6

Focus ring

7

Mounting holes for wall mount: Screw hole M4 x 8 mm depth.
Recommended torque <10 kgf-cm

163.00

1

12.50

38.80

151.30

7

4

1

2

6

3

4

5

Top View

Bottom View
