Removing and Installing Parts: Dell Dimension 9200C Service Manual
file:///T|/htdocs/systems/dim9200C/en/SM_EN/parts.htm[10/31/2012 8:07:53 AM]
NOTICE: Do not pull the drive out of the computer by the drive cables. Doing so may cause damage to the cables and
cable connectors.
3. Lift the drive out of the computer and disconnect the power and hard-drive cables from the drive.
1 power cable 2 hard drive cable or serial ATA data cable
Installing a Hard Drive
1. Follow the procedures in Before You Begin .
2. Remove the old hard drive, as needed (see Removing a Hard Drive ).
3. Unpack the hard drive, and prepare it for installation.
4. Check the documentation for the drive to verify that it is configured for your computer.
NOTE: If your replacement hard drive does not have the plastic guide bracket attached, remove the bracket from the
old drive by unsnapping it from the drive. Snap the bracket onto the new drive.
